Progettazione della logica di transizione
R2026aCreare transizioni tra gli stati per gestire il flusso logico del grafico. Definire le condizioni di transizione utilizzando eventi, condizioni sui dati e logica temporale. Utilizzare le azioni di transizione per eseguire attività e calcoli durante le modifiche di stato.
Argomenti
- Create Transitions Between States
Connect states in charts and define how your system moves between operating modes with transitions.
- Construct Decision Points by Using Junctions
Use junctions to branch paths between states, implement conditional logic, and design flow charts.
- Manage Transition Execution with Operators
Design Stateflow charts that respond to changes in data values by connecting transitions and actions to data conditions.
- Troubleshoot Condition Actions Executing Repeatedly or at Unexpected Times
Troubleshoot unexpected action execution or performance loss caused by branching paths in charts.
Esempi in primo piano
Schedule Operations in a Hydraulic Control System
Implement mode-based execution and event-driven scheduling in a hydraulic landing gear control system by using Stateflow® to coordinate multiple Simulink® subsystems. Hydraulic landing gear systems require mode-based scheduling to coordinate operations at different flight phases and event-driven control to respond to sensor feedback and safety conditions.
