PFC with buck-boost converter

Versione 1.0.0 (36,6 KB) da Abdelrahman Farghly
Buck-Boost converter used for Power Factor Correction (PFC) allows the output voltage to be either higher or lower than the input AC peak
0.0
(0)
76 download
Aggiornato 10 mag 2025

Visualizza la licenza

Control Strategy – Two Loops
1. Outer Voltage Loop (PI Controller)
  • Regulates output DC voltage
  • Generates the amplitude of the current reference
2. Inner Current Loop
  • Shapes input current to follow AC voltage waveform
  • Can be implemented via:
  • Hysteresis current control (fast, simple)
  • Average current mode control (more stable)
  • Peak current mode control
