filterAnalyzer
Description
The filterAnalyzer
object analyzes responses of input filters using
the Filter Analyzer
app.
Creation
Syntax
Description
filterAnalyzer
opens the Filter Analyzer
app.
filterAnalyzer(
specifies additional options using one or more name-value arguments. For example, you
can specify filter names, sample rates, or analysis options.filt
1,...,filt
n,Name=Value
)
filterAnalyzer(
opens a
Filter Analyzer session stored in the MAT-file called
filename
)filename
. If Filter Analyzer is already open, this
syntax replaces the current app session with the new session.
filterAnalyzer(
appends
the filters stored in the MAT-file called filename
,"append")filename
to the current
Filter Analyzer session. If Filter Analyzer is not open, this
syntax is equivalent to the previous syntax.
Input Arguments
Output Arguments
Object Functions
addDisplays | Add new analysis displays to Filter Analyzer app |
addFilters | Add new filters to Filter Analyzer app |
clearLegendStrings | Clear alternative legend strings for filters in Filter Analyzer app |
close | Close the Filter Analyzer app |
deleteDisplays | Delete displays from Filter Analyzer app |
deleteFilters | Delete filters from Filter Analyzer app |
duplicateDisplays | Duplicate displays in Filter Analyzer app |
getAnalysisOptions | Get analysis options of displays in Filter Analyzer app |
newSession | Clear Filter Analyzer app session and start a new one |
renameFilters | Update filter names in Filter Analyzer app |
replaceFilters | Replace existing filters with new filters in Filter Analyzer app |
saveSession | Save Filter Analyzer app session |
setAnalysisOptions | Set analysis options of displays in Filter Analyzer app |
setLegendStrings | Define alternative legend strings for filters in Filter Analyzer app |
showFilters | Show filters in Filter Analyzer app |
showLegend | Toggle display legends in Filter Analyzer app |
showSpecificationMask | Toggle filter specification mask of displays in Filter Analyzer app |
showUserDefinedMask | Specify and toggle user-defined spectral mask in Filter Analyzer app displays |
zoom | Zoom into region of interest in Filter Analyzer app displays |
Examples
Version History
Introduced in R2024a
