Tapped Delay

Delay scalar signal multiple sample periods and output all delayed versions

  • Library:
  • Simulink / Discrete

    HDL Coder / Discrete

Description

The Tapped Delay block delays an input by the specified number of sample periods and outputs all the delayed versions. Use this block to discretize a signal in time or resample a signal at a different rate.

The block accepts one scalar input and generates an output vector that contains each delay. Specify the order of the delays in the output vector with the Order output vector starting with parameter:

  • Oldest orders the output vector starting with the oldest delay version and ending with the newest delay version.

  • Newest orders the output vector starting with the newest delay version and ending with the oldest delay version.

Specify the output vector for the first sampling period with the Initial condition parameter. Careful selection of this parameter can minimize unwanted output behavior.

Specify the time between samples with the Sample time parameter. Specify the number of delays with the Number of delays parameter. A value of -1 instructs the block to inherit the number of delays by backpropagation. Each delay is equivalent to the z-1 discrete-time operator, which the Unit Delay block represents.

Ports

Input

expand all

Input signal to delay, specified as a scalar.

Data Types: single | double | int8 | int16 | int32 | uint8 | uint16 | uint32 | Boolean | fixed point

Output

expand all

Output signal is all delayed versions of the input signal. Use the Order output vector starting with parameter to specify the order of delayed signals in the output vector.

Data Types: single | double | int8 | int16 | int32 | uint8 | uint16 | uint32 | Boolean | fixed point

Parameters

expand all

Specify the initial output of the simulation. The Initial condition parameter is converted from a double to the input data type offline using round-to-nearest and saturation.

Limitations

The initial condition of this block cannot be inf or NaN.

Programmatic Use

Block Parameter: vinit
Type: character vector
Values: scalar | vector | matrix
Default: '0.0'

Specify the time interval between samples. To inherit the sample time, set this parameter to -1. For more information, see Specify Sample Time.

Programmatic Use

Block Parameter: samptime
Type: character vector
Values: scalar | vector
Default: '-1'

Specify the number of discrete-time operators as a positive scalar, or -1 for inherited.

Programmatic Use

Block Parameter: NumDelays
Type: character vector
Values: positive scalar | -1 (inherited)
Default: '4'

Specify whether to output the oldest delay version first, or the newest delay version first.

Programmatic Use

Block Parameter: DelayOrder
Type: character vector
Values: 'Oldest' | 'Newest'
Default: 'Oldest'

Select this check box to include the current input in the output vector.

Programmatic Use

Block Parameter: includeCurrent
Type: character vector
Values: 'off' | 'on'
Default: 'off'

Block Characteristics

Data Types

Boolean | double | fixed point | integer | single

Direct Feedthrough

no

Multidimensional Signals

no

Variable-Size Signals

no

Zero-Crossing Detection

no

Extended Capabilities

C/C++ Code Generation
Generate C and C++ code using Simulink® Coder™.

PLC Code Generation
Generate Structured Text code using Simulink® PLC Coder™.

Fixed-Point Conversion
Convert floating-point algorithms to fixed point using Fixed-Point Designer™.

Introduced before R2006a
