## Generalized Linear Model Workflow

This example shows how to fit a generalized linear model and analyze the results. A typical workflow involves the following: import data, fit a generalized linear model, test its quality, modify it to improve the quality, and make predictions based on the model. It computes the probability that a flower is in one of two classes, based on the Fisher iris data.

### Step 1. Load the data.

Load the Fisher iris data. Extract the rows that have classification versicolor or virginica. These are rows 51 to 150. Create logical response variables that are true for versicolor flowers.

X = meas(51:end,:); % versicolor and virginica
y = strcmp('versicolor',species(51:end));

### Step 2. Fit a generalized linear model.

Fit a binomial generalized linear model to the data.

mdl = fitglm(X,y,'linear',...
'distr','binomial')
mdl =
Generalized linear regression model:
logit(y) ~ 1 + x1 + x2 + x3 + x4
Distribution = Binomial

Estimated Coefficients:
Estimate      SE       tStat      pValue
________    ______    _______    ________

(Intercept)     42.638     25.708     1.6586    0.097204
x1              2.4652     2.3943     1.0296     0.30319
x2              6.6809     4.4796     1.4914     0.13585
x3             -9.4294     4.7372    -1.9905    0.046537
x4             -18.286     9.7426    -1.8769    0.060529

100 observations, 95 error degrees of freedom
Dispersion: 1
Chi^2-statistic vs. constant model: 127, p-value = 1.95e-26

### Step 3. Examine the result, consider alternative models.

Some $p$-values in the pValue column are not very small. Perhaps the model can be simplified.

See if some 95% confidence intervals for the coefficients include 0. If so, perhaps these model terms could be removed.

confint = coefCI(mdl)
confint = 5×2

-8.3984   93.6740
-2.2881    7.2185
-2.2122   15.5739
-18.8339   -0.0248
-37.6277    1.0554

Only two of the predictors have coefficients whose confidence intervals do not include 0.

The coefficients of 'x1' and 'x2' have the largest $p$-values. Test whether both coefficients could be zero.

M = [0 1 0 0 0     % picks out coefficient for column 1
0 0 1 0 0];   % picks out coefficient for column 2
p = coefTest(mdl,M)
p = 0.1442

The $p$-value of about 0.14 is not very small. Drop those terms from the model.

mdl1 = removeTerms(mdl,'x1 + x2')
mdl1 =
Generalized linear regression model:
logit(y) ~ 1 + x3 + x4
Distribution = Binomial

Estimated Coefficients:
Estimate      SE       tStat       pValue
________    ______    _______    __________

(Intercept)     45.272     13.612      3.326    0.00088103
x3             -5.7545     2.3059    -2.4956      0.012576
x4             -10.447     3.7557    -2.7816     0.0054092

100 observations, 97 error degrees of freedom
Dispersion: 1
Chi^2-statistic vs. constant model: 118, p-value = 2.3e-26

Perhaps it would have been better to have stepwiseglm identify the model initially.

mdl2 = stepwiseglm(X,y,...
'constant','Distribution','binomial','upper','linear')
1. Adding x4, Deviance = 33.4208, Chi2Stat = 105.2086, PValue = 1.099298e-24
2. Adding x3, Deviance = 20.5635, Chi2Stat = 12.8573, PValue = 0.000336166
3. Adding x2, Deviance = 13.2658, Chi2Stat = 7.29767, PValue = 0.00690441
mdl2 =
Generalized linear regression model:
logit(y) ~ 1 + x2 + x3 + x4
Distribution = Binomial

Estimated Coefficients:
Estimate      SE       tStat      pValue
________    ______    _______    ________

(Intercept)     50.527     23.995     2.1057    0.035227
x2              8.3761     4.7612     1.7592    0.078536
x3             -7.8745     3.8407    -2.0503    0.040334
x4              -21.43     10.707    -2.0014     0.04535

100 observations, 96 error degrees of freedom
Dispersion: 1
Chi^2-statistic vs. constant model: 125, p-value = 5.4e-27

stepwiseglm included 'x2' in the model, because it neither adds nor removes terms with $p$-values between 0.05 and 0.10.

### Step 4. Look for outliers and exclude them.

Examine a leverage plot to look for influential outliers.

plotDiagnostics(mdl2,'leverage')

There is one observation with a leverage close to one. Using the Data Cursor, click the point, and find it has index 69.

See if the model coefficients change when you fit a model excluding this point.

oldCoeffs = mdl2.Coefficients.Estimate;
mdl3 = fitglm(X,y,'linear',...
'distr','binomial','pred',2:4,'exclude',69);
newCoeffs = mdl3.Coefficients.Estimate;
disp([oldCoeffs newCoeffs])
50.5268   50.5268
8.3761    8.3761
-7.8745   -7.8745
-21.4296  -21.4296

The model coefficients do not change, suggesting that the response at the high-leverage point is consistent with the predicted value from the reduced model.

### Step 5. Predict the probability that a new flower is versicolor.

Use mdl2 to predict the probability that a flower with average measurements is versicolor. Generate confidence intervals for your prediction.

[newf,newc] = predict(mdl2,mean(X))
newf = 0.5086
newc = 1×2

0.1863    0.8239

The model gives almost a 50% probability that the average flower is versicolor, with a wide confidence interval about this estimate.
