Matsim
Matsim is a high level interface to create Simulink models from a Matlab script. Matsim is a wrapper around the standard simulink API that makes building a simulink model programmatically much faster.
Convert function handle to simulink model:
h = @(x,y) 1-x+min(0,y);
fun2model(h);
Build simulink model from script:
import matsim.library.*
sys = simulation.load('my_model'); % Create and open a model named 'my_model'
sys.show();
a = FromWorkspace('var1'); % Create FromWorkspace block
b = FromWorkspace('var2');
res = Min(a,b); % Create MinMax block with block "a" and block "b" as inputs
s = Scope(res); % Create scope block
sys.layout() % Connect and layout model
Key features:
- Automatic layout (no need to specify block positions!)
- Intuitive interface (you can "add","subtract","multiply",... simulink blocks)
- Extensible library (easily add new blocks from your custom libraries)
For installation instruction and detailed examples see:
https://github.com/gave92/Matsim/blob/master/README.md
