Would like to know what is this symbol and its function

3 visualizzazioni (ultimi 30 giorni)

Good day community, can I know what is this symbol could be? It looks like a ramp/ continuous ramp. But I believe it is not both them. I saw someone connect it after a voltage/ current measurement. Can I know what is the function of this symbol too? Much appreciate for the answers given

  2 Commenti
Kilsu Kim
Kilsu Kim il 26 Ott 2023
It looks like "Saturation" block but the direction of the block is opposite.
Ying Jie Tan
Ying Jie Tan il 26 Ott 2023

I've think about this before, but if Im not mistaken, the saturation block came with the y and x axis too right? Or we can hide that axes to become like the block I've attached above?
