How to Call MATLAB from Python
This video is a companion to the video about calling Python® from MATLAB. It shows how to call MATLAB® code from Python using a sentiment analysis example. In this example, Python is used for listening to audio through a microphone and detecting text from speech. Then a pretrained machine learning model in MATLAB is used to predict the sentiment (positive, negative, or neutral) of the detected text. First, you will see how the MATLAB Engine API for Python can be used to directly call MATLAB as a computational engine from Python code. Next, you will learn how to deploy MATLAB code as a Python package using MATLAB Compiler SDK™. This deployed package requires only the MATLAB Runtime, which enables you to share your code royalty free with users who do not need MATLAB.
In this video, you will learn how to call MATLAB code from Python.
To do this, we will use a sentiment analysis example. Suppose a person says that was the best concert they ever attended. A sentiment analysis algorithm will look at this text and output what it thinks is the intent – or the sentiment – of the person. In this case, it should predict that this is a positive statement. On the other hand, if the person says they dropped their ice cream on the floor and they are sad, then the algorithm should predict a negative sentiment.
The sentiment analysis program might look like this. We listen to an audio source like a microphone, detect text from the audio signal, and then classify the text using our sentiment analysis model. Suppose I am doing all my development in Python, but my colleague already has MATLAB code to perform sentiment analysis on text. Instead of rewriting code or finding a new solution, I want to still use the MATLAB code for sentiment analysis and do the rest of my work in Python.
There are two approaches for calling MATLAB code from Python. The first is to use the MATLAB Engine API for Python, which requires a MATLAB install. The second is to use MATLAB Compiler SDK to compile a Python package that does not require users to have a MATLAB install.
Let’s first see our MATLAB code. This is a simple test script where I can write a sentence and pass it into my sentiment analysis function. The idea is to call this same function from the rest of our code that is written in Python. As you can see, the predicted sentiment is neutral, which seems correct. If you’re wondering what’s in this function, I am using a built-in sentiment analysis algorithm called VADER from Text Analytics Toolbox.
Now, let’s go to Python. I have a module that uses the SpeechRecognition package, and particularly the PocketSphinx software from Carnegie Mellon University, to recognize text from speech. In this package, my colleague provided a “speechToText” function. This listens to an audio device, such as a microphone, and returns the detected text and a Boolean flag indicating whether the detection was successful.
Here is a notebook showing the process using the MATLAB Engine API for Python. Recall that this approach requires the user to have a licensed installation of MATLAB on their machine.
I will first import the speech recognition and MATLAB Engine modules.
Then, I will start a new MATLAB process which returns an object for communicating with this process.
Let’s use the built-in “speechToText” function in our module to listen to my microphone and display the detected text. For example, “I went to my favorite restaurant and had a delicious meal”.
Now that we have the detected text, it’s time to call the MATLAB code. With this line of code, I am instructing MATLAB to call the “sentimentAnalysisVADER” function. My inputs are the detected text, and the number of output arguments I want to assign – in this case, two. As you can see from the printed outputs, the predicted sentiment is positive.
Now that we are done running MATLAB code, let’s shut down the session.
Let’s explore the second approach which is to compile a Python package from our MATLAB code. To do this, I will go to the Apps tab in MATLAB and open the Library Compiler app. I will select an output type of “Python Package” and then add my “sentimentAnalysisVADER” function for export.
You can fill in the rest of the settings with useful information and documentation, but I will jump ahead to the “Samples” section. Here is where you can provide sample code that calls your exported functions, and the Library Compiler app will automatically generate equivalent Python samples to show you how to call the package. Let’s add our test script from earlier.
Now, we can select “Package” to create our standalone component. When this is done, I can look at the output folder, and in the “samples” folder you can see the Python equivalent of the MATLAB test script I provided.
Going back to Python, here is my notebook showing the compiled package approach. Users can run these compiled packages with the MATLAB Runtime, which you can directly share with your users, or they can download it from the MathWorks website.
Note that, before running this code, both the compiled package and MATLAB Runtime need to be installed. Please refer to the documentation for steps on how to do this.
I will first import the speech recognition module and the package we just generated.
Then, I will call the “initialize” function of the compiled package to start a MATLAB Runtime.
Now that we have the detected text, we can call the “sentimentAnalysisVADER” function. My inputs are the detected text, and the number of output arguments I want to assign – in this case, two. As you can see from the printed outputs, the predicted sentiment is negative.
And finally, let’s terminate the MATLAB Runtime.
That concludes our example. To summarize, let’s talk about why you would want to call MATLAB from Python. The workflow we showed fits if you are already working in Python and want to use MATLAB to solve part of the problem. This could be either that you have existing MATLAB code you would like to reuse, or you need to access functionality that is only available in MATLAB and its various toolboxes and add-ons. In addition, you can use MATLAB Compiler SDK to compile Python packages that can be shared with users that do not have MATLAB installed.
To learn more, check out the resources below. Also, make sure to watch our other video on how to call Python from MATLAB.
