Jack Erickson, MathWorks
Prototyping a design on an FPGA enables high-speed processing of real-world input, but debugging when problems occur is extremely difficult due to the lack of visibility of internal signals. FPGA Data Capture in HDL Verifier™ enables you to define signals in the FPGA to probe, and automatically generates the components needed to connect your FPGA board to MATLAB® or Simulink® to analyze signals. See this capability in action, together with Logic Analyzer, using an audio design example.
Recorded: 8 Mar 2017
