Object Detection

Perform classification, object detection, transfer learning using convolutional neural networks (CNNs, or ConvNets), create customized detectors

Object detection is a computer vision technique for locating instances of objects in images or videos. Object detection algorithms typically leverage machine learning or deep learning to produce meaningful results. When looking at images or video, humans can recognize and locate objects of interest in a matter of moments. The goal of object detection is to replicate this intelligence using a computer. The best approach for object detection depends on your application and the problem you are trying to solve.

Deep learning techniques require a large number of labeled training images, so the use of a GPU is recommended to decrease the time needed to train a model. Deep learning-based approaches to object detection use convolutional neural networks (CNNs or ConvNets), such as R-CNN and YOLO, or use single-shot detection (SSD). You can train a custom object detector, or use a pretrained object detector by leveraging transfer learning, an approach that enables you to start with a pretrained network and then fine-tune it for your application. Convolutional neural networks require Deep Learning Toolbox™. Training and prediction are supported on a CUDA®-capable GPU. Use of a GPU is recommended and requires Parallel Computing Toolbox™. For more information, see Preferenze Computer Vision Toolbox and Parallel Computing Support in MathWorks Products (Parallel Computing Toolbox).

Machine learning techniques for object detection include aggregate channel features (ACF), support vector machines (SVM) classification using histograms of oriented gradient (HOG) features, and the Viola-Jones algorithm for human face or upper-body detection. You can choose to start with a pretrained object detector or create a custom object detector to suit your application.

Labeled boats, neural network, and person detector


Image LabelerLabel images for computer vision applications
Video LabelerLabel video for computer vision applications


espandi tutto

Deep Learning Detectors

rcnnObjectDetectorDetect objects using R-CNN deep learning detector
fastRCNNObjectDetectorDetect objects using Fast R-CNN deep learning detector
fasterRCNNObjectDetectorDetect objects using Faster R-CNN deep learning detector
ssdObjectDetectorDetect objects using SSD deep learning detector (Da R2020a)
yolov2ObjectDetectorDetect objects using YOLO v2 object detector (Da R2019a)
yolov3ObjectDetectorDetect objects using YOLO v3 object detector (Da R2021a)
yolov4ObjectDetectorDetect objects using YOLO v4 object detector (Da R2022a)
solov2Segment objects using SOLOv2 instance segmentation network (Da R2023b)
maskrcnnDetect objects using Mask R-CNN instance segmentation (Da R2021b)
ocrRecognize text using optical character recognition

Feature-based Detectors

readAprilTagDetect and estimate pose for AprilTag in image (Da R2020b)
readBarcodeDetect and decode 1-D or 2-D barcode in image (Da R2020a)
acfObjectDetectorDetect objects using aggregate channel features
peopleDetectorACFDetect people using aggregate channel features
vision.CascadeObjectDetectorDetect objects using the Viola-Jones algorithm
vision.ForegroundDetectorForeground detection using Gaussian mixture models
vision.PeopleDetectorDetect upright people using HOG features
vision.BlobAnalysisProperties of connected regions

Detect Objects Using Point Features

detectBRISKFeaturesDetect BRISK features
detectFASTFeaturesDetect corners using FAST algorithm
detectHarrisFeaturesDetect corners using Harris–Stephens algorithm
detectKAZEFeaturesDetect KAZE features
detectMinEigenFeaturesDetect corners using minimum eigenvalue algorithm
detectMSERFeaturesDetect MSER features
detectORBFeaturesDetect ORB keypoints (Da R2019a)
detectSIFTFeaturesDetect scale invariant feature transform (SIFT) features (Da R2021b)
detectSURFFeaturesDetect SURF features
extractFeaturesExtract interest point descriptors
matchFeaturesFind matching features

Select Detected Objects

selectStrongestBboxSelect strongest bounding boxes from overlapping clusters using nonmaximal suppression (NMS)
selectStrongestBboxMulticlassSelect strongest multiclass bounding boxes from overlapping clusters using nonmaximal suppression (NMS

Load Training Data

boxLabelDatastoreDatastore for bounding box label data (Da R2019b)
groundTruthGround truth label data
imageDatastoreDatastore for image data
objectDetectorTrainingDataCreate training data for an object detector
ocrTrainingOptionsOptions for training OCR model (Da R2023a)
combineCombine data from multiple datastores (Da R2019a)

Train Feature-Based Object Detectors

trainACFObjectDetectorTrain ACF object detector
trainCascadeObjectDetectorTrain cascade object detector model
trainImageCategoryClassifierTrain an image category classifier

Train Deep Learning Based Object Detectors

trainRCNNObjectDetectorTrain an R-CNN deep learning object detector
trainFastRCNNObjectDetectorTrain a Fast R-CNN deep learning object detector
trainFasterRCNNObjectDetectorTrain a Faster R-CNN deep learning object detector
trainSSDObjectDetectorTrain an SSD deep learning object detector (Da R2020a)
trainYOLOv2ObjectDetectorTrain YOLO v2 object detector (Da R2019a)
trainYOLOv4ObjectDetectorTrain YOLO v4 object detector (Da R2022a)
trainSOLOV2Train SOLOv2 network to perform instance segmentation (Da R2023b)
trainMaskRCNNTrain Mask R-CNN network to perform instance segmentation (Da R2022a)
ocrTrainingOptionsOptions for training OCR model (Da R2023a)
trainOCRTrain OCR model to recognize text in image (Da R2023a)
quantizeOCRQuantize OCR model (Da R2023a)

Augment and Preprocess Training Data for Deep Learning

balanceBoxLabelsBalance bounding box labels for object detection (Da R2020a)
bboxcropCrop bounding boxes (Da R2019b)
bboxeraseRemove bounding boxes (Da R2021a)
bboxresizeResize bounding boxes (Da R2019b)
bboxwarpApply geometric transformation to bounding boxes (Da R2019b)
bbox2pointsConvert rectangle to corner points list
imwarpApply geometric transformation to image
imcropCrop image
imresizeResize image
randomAffine2dCreate randomized 2-D affine transformation (Da R2019b)
centerCropWindow2dCreate rectangular center cropping window (Da R2019b)
randomWindow2dRandomly select rectangular region in image (Da R2021a)
integralImageCalculate 2-D integral image

R-CNN (Regions With Convolutional Neural Networks)

rcnnBoxRegressionLayerBox regression layer for Fast and Faster R-CNN
fasterRCNNLayersCreate a faster R-CNN object detection network (Da R2019b)
rpnSoftmaxLayerSoftmax layer for region proposal network (RPN)
rpnClassificationLayerClassification layer for region proposal networks (RPNs)
regionProposalLayerRegion proposal layer for Faster R-CNN
roiAlignLayerNon-quantized ROI pooling layer for Mask-CNN (Da R2020b)
roiInputLayerROI input layer for Fast R-CNN
roiMaxPooling2dLayerNeural network layer used to output fixed-size feature maps for rectangular ROIs
roialignNon-quantized ROI pooling of dlarray data (Da R2021b)

YOLO v2 (You Only Look Once version 2)

yolov2LayersCreate YOLO v2 object detection network (Da R2019a)
yolov2TransformLayerCreate transform layer for YOLO v2 object detection network (Da R2019a)
yolov2OutputLayerCreate output layer for YOLO v2 object detection network (Da R2019a)
spaceToDepthLayerSpace to depth layer (Da R2020b)

Focal Loss Layers

focalLossLayerCreate focal loss layer using focal loss function (Da R2020a)
focalCrossEntropyCompute focal cross-entropy loss (Da R2020b)

SSD (Single Shot Detector)

ssdMergeLayerCreate SSD merge layer for object detection (Da R2020a)

Anchor Boxes

estimateAnchorBoxesEstimate anchor boxes for deep learning object detectors (Da R2019b)
cuboid2imgProject cuboids from 3-D world coordinates to 2-D image coordinates (Da R2022b)
insertObjectAnnotationAnnotate truecolor or grayscale image or video
insertObjectMask Insert masks in image or video stream (Da R2020b)
insertShapeInsert shapes in image or video
showShapeDisplay shapes on image, video, or point cloud (Da R2020b)
evaluateObjectDetectionEvaluate object detection data set against ground truth (Da R2023b)
objectDetectionMetricsObject detection quality metrics (Da R2023b)
evaluateInstanceSegmentationEvaluate instance segmentation data set against ground truth (Da R2022b)
instanceSegmentationMetricsInstance segmentation quality metrics (Da R2022b)
bboxOverlapRatioCompute bounding box overlap ratio
bboxPrecisionRecallCompute bounding box precision and recall against ground truth
evaluateOCREvaluate OCR results against ground truth (Da R2023a)
evaluateDetectionMissRate(To be removed) Evaluate miss rate metric for object detection
evaluateDetectionPrecision(To be removed) Evaluate precision metric for object detection
evaluateDetectionAOS(To be removed) Evaluate average orientation similarity metric for object detection (Da R2020a)


Deep Learning Object DetectorDetect objects using trained deep learning object detector (Da R2021b)


Get Started

Training Data for Object Detection and Instance Segmentation

Get Started With Deep Learning

  • Deep Network Designer (Deep Learning Toolbox)
  • List of Deep Learning Layers (Deep Learning Toolbox)
    Discover all the deep learning layers in MATLAB®.
  • Deep Learning in MATLAB (Deep Learning Toolbox)
    Scoprire le capacità del Deep Learning in MATLAB utilizzando le reti neurali convoluzionali per la classificazione e la regressione, incluse le reti preaddestrate e il transfer learning, nonché l’addestramento su GPU, CPU, cluster e cloud.
  • Reti neurali profonde preaddestrate (Deep Learning Toolbox)
    Apprendere come scaricare e utilizzare le reti neurali convoluzionali preaddestrate per la classificazione, il transfer learning e l’estrazione di feature.
